3567 Nidec 3/4 Hp 825 RPM 208-230V 6.5" Dia. (No Base) 1-Speed ODP Condenser Motor

3567 Nidec 3/4 Hp 825 RPM 208-230V 6.5" Dia. (No Base) 1-Speed ODP Condenser Motor - Image 2

3567 Nidec 3/4 Hp 825 RPM 208-230V 6.5″ Dia. (No Base) 1-Speed ODP Condenser Motor

Original price was: $367.00.Current price is: $95.99.

SKU: ZWXLY 1698667592 Categories: Air Condenser Fan Motor, HVAC Motors & Draft Inducers Tag: Nidec

Have the best deals
The quality solution for all your needs.
Excellent customer service online in a timely manner
The best quality products, always.

Description
Reviews (0)

3/4 hp 825 RPM, 5.3 amps 208-230V Volts 60 Hz PSC Motor
NEMA 6.5″ Dia. Frame, Rolled Steel, Flat Shaft 5/8″ Diameter x 6″
Service Factor = 1, Overload Protection: Auto
Stud Mount, Ball Bearings, Class B Insulation, Rev
1 Year Manufacture Warranty

Replacement Condenser Fan Motor for certain brands. Wiring diagram on motor name plate. ODP = Open Drip Proof, K0630WP4016862B
