D3P2D Nidec | 3 Hp 1800 RPM 182T Frame 208-230/460V ODP Motor Electric Motor Nidec
Original price was: $384.00.$97.99Current price is: $97.99.
- Have the best deals
- The quality solution for all your needs.
- Excellent customer service online in a timely manner
- The best quality products, always.
- 3 hp 1800 RPM, 7.6/3.8 amps 208-230/460 Volts 50/60hz. Three Phase
- NEMA 182T frame Keyed Shaft 1-1/8″ x 2 3/4″
- ODP; Service Factor: 1.15, Overload protection = None
- Reversible, Rigid Base Mount, Ball Bearings, Class F Insulation
- 1 Year Manufacture Warranty
General purpose motor can be used for many applications requiring a three phase electric motor. Continuous Duty. Premium efficient. 40C Ambient Temp. Wiring diagram on motor name plate. ODP = Open Drip Proof
Model HE22, Dayton 263Z40
